The LP6496 is a synchronous step down regulator with CC control from a high voltage input supply. Operating with an input voltage 8V~40V, the LP6496 achieves 5A continuous output current with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization. The LP6496 requires a minimum number of readily available standard external components. Other features include cable compensation, programmable current limit and thermal shutdown.The LP6496 converters are available in the industry standard SOP8 packages.
应用
◆ Car Charger / Adaptor ◆ LED Driver ◆ Pre-Regulator for Linear Regulators ◆ Distributed Power Systems ◆ Battery Charge
数据参数
数据参数
输入电压(V)
8.0~40
输出电压(V)
0.6~40
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
180K
最大输出电流(A)
4.8
输出通道数量
1
工作模式
Syn.
EN控制
N
轻负载模式
FCCM
产品特征/功能
Adjustable output current limit,Line compensation
封装
SOP8
特征
特征
◆ Wide Input Voltage Range: 8V ～ 40V ◆ Up to 94% Efficiency ◆ No Loop Compensation Required ◆ CC/CV control ◆ Programmable CC Current ◆ Thermal Shutdown ◆ Available in SOP8 Package
