| 产品型号 | 输入电压(V) | 静态电流(uA) | 输出电流 (A) | 特点 | 封装 |
|---|---|---|---|---|---|
LP1131
|
4.3~13.2 | 900 | 5 | 半桥+LDO | ESOP8 |
|
LP1150
|
4.0~24 | 2500 | 12*2 | 全桥 | FCQFN-24 (4*4) |
| 产品型号 | 封装 | DS电压最大值(V) | GS电压最大值(V) | VGS（TH） -TYP(V) | 输出电流(A) | RDSON (mΩ) at VGS=2.5V （TYP) | RDSON (mΩ) at VGS=2.5V （MAX) | RDSON (mΩ) at VGS=4.5V （TYP) | RDSON (mΩ) at VGS=4.5V （MAX) | RDSON (mΩ) at VGS=10V （TYP) | RDSON (mΩ) at VGS=10V （MAX) | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LPM04N046GD
|
TO252 | 40 | ±20 | 1.6 | 80 | - | - | 5.5 | 7.4 | 4.5 | 5.8 | SGT |
|
LPM04N046GN
|
PDFN5*6 | 40 | ±20 | 1.35 | 72 | - | - | 5.5 | 7.4 | 4.5 | 5.8 | SGT |
|
LPM04N046GE
|
PDFN3*3 | 40 | ±20 | 1.35 | 60 | - | - | 5.5 | 7.4 | 4.5 | 5.8 | SGT |
|
LPM04N025GD
|
TO252 | 40 | ±20 | 1.5 | 90 | - | - | 3.3 | 3.8 | 2.5 | 3.2 | SGT |
|
LPM04N025GE
|
PDFN3*3 | 40 | ±20 | 1.5 | 120 | - | - | 3.6 | 4.5 | 2.9 | 3.6 | SGT |
|
LPM04N025GN
|
PDFN5*6 | 40 | ±20 | 1.5 | 130 | - | - | 3.3 | 3.8 | 2.5 | 3.3 | SGT |
|
LPM04N013GN
|
PDFN5*6 | 40 | ±20 | 1.7 | 200 | - | - | 1.75 | 2.3 | 1.35 | 1.7 | SGT |
|
LPM04N007GN
|
PDFN5*6 | 40 | ±20 | 1.7 | 265 | - | - | 1.05 | 1.4 | 0.75 | 1 | SGT |
|
LPM9040
|
DFN-8(3*3) | 40 | ±20 | 2.2 | 20 | - | - | 10 | 12.5 | 8.2 | 10 | Trench |
|
LPM03N075TE
|
PDFN3*3 | 30 | ±20 | 1.45 | 32 | - | - | 9.8 | 13 | 7.5 | 9.7 | Trench |
|
LPM03N042GN
|
PDFN5*6 | 30 | ±20 | 1.7 | 58 | - | - | 6 | 8 | 4.2 | 5.5 | SGT |
|
LPM03N042GE
|
PDFN3*3 | 30 | ±20 | 1.7 | 50 | - | - | 6 | 8 | 4.2 | 5.5 | SGT |
|
LPM03N042GK
|
DFN2*2 | 30 | ±20 | 1.7 | 30 | - | - | 6 | 8 | 4.2 | 5.5 | SGT |
|
LPM03N038GN
|
PDFN5*6 | 30 | ±20 | 1.5 | 65 | - | - | 6 | 7.5 | 4.1 | 5.5 | SGT |
|
LPM03N038GE
|
PDFN3*3 | 30 | ±20 | 1.5 | 50 | - | - | 6 | 7.5 | 4.1 | 5.5 | SGT |
|
LPM03N018GD
|
TO252 | 30 | ±20 | 1.6 | 150 | - | - | 3.1 | 4 | 2.2 | 2.8 | SGT |
|
LPM03N018GN
|
PDFN5*6 | 30 | ±20 | 1.6 | 128 | - | - | 3.1 | 4 | 2.2 | 2.8 | SGT |
|
LPM03N018GE
|
PDFN3*3 | 30 | ±20 | 1.6 | 110 | - | - | 3.1 | 4 | 2.2 | 2.8 | SGT |
|
LPM03N014GN
|
PDFN5*6 | 30 | ±20 | 1.7 | 168 | - | - | 2 | 2.75 | 1.35 | 1.85 | SGT |
|
LPM03N009GN
|
PDFN5*6 | 30 | ±20 | 1.6 | 242 | - | - | 1.35 | 1.7 | 0.95 | 1.2 | SGT |
|
LPM03N018GE
|
DFN-8(3*3) | 30 | ±20 | 1.8 | 110 | - | - | 3.1 | 4 | 2.2 | 2.8 | SGT |
LPM03N038GE
|
DFN-8(3*3) | 30 | ±20 | 1.5 | 60 | - | - | 6.3 | 7.9 | 4.5 | 5.5 | SGT |
|
LPM03N042GE
|
DFN-8(3*3) | 30 | ±20 | 1.75 | 50 | - | - | 6 | 8 | 4.2 | 5.5 | SGT |
|
LPM03N042GK
|
DFN-6(2*2) | 30 | ±20 | 1.7 | 20 | - | - | 6 | 8 | 4.2 | 5.5 | SGT |
|
LPM03N075TK
|
DFN2*2 | 30 | ±20 | 1.45 | 14 | - | - | 9.8 | 13 | 7.5 | 9.7 | Trench |
|
LPM9040A
|
DFN-8(3*3) | 30 | ±20 | 2.2 | 20 | - | - | 10 | 12.5 | 8.2 | 10 | Trench |
|
LPM3406
|
SOT23 | 30 | ±20 | 1.8 | 3.6 | - | - | 62 | - | 48 | - | Trench |
|
LPM9926
|
SOP8 | 20 | ±12 | 0.75 | 7.6 | 24 | 38 | 18.5 | 28 | 16.5 | 23 | Trench |
|
LPM3414
|
SOT23 | 20 | ±8 | 0.6 | 3 | 52 | 62 | 41 | 50 | - | - | Trench |
|
LPM3400
|
SOT23 | 20 | ±8 | 1.1 | 4.2 | 43 | 52 | 27 | 33 | 22 | 28 | Trench |
|
LPM2302
|
SOT23 | 20 | ±12 | 0.7 | 3.5 | 75 | - | 50 | - | - | - | Trench |
| 产品型号 | 封装 | DS电压最大值(V) | GS电压最大值(V) | VGS（TH） -TYP(V) | 输出电流(A) | RDSON (mΩ) at VGS=2.5V （TYP) | RDSON (mΩ) at VGS=2.5V （MAX) | RDSON (mΩ) at VGS=4.5V （TYP) | RDSON (mΩ) at VGS=4.5V （MAX) | RDSON (mΩ) at VGS=10V （TYP) | RDSON (mΩ) at VGS=10V （MAX) | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LPM06P700TS
|
SO8 | -60 | ±20 | -1.8 | -4.5 | - | - | 92 | 120 | 83 | 98 | Trench |
|
LPM06P700TD
|
TO252 | -60 | ±20 | -1.8 | -35 | - | - | 92 | 120 | 83 | 98 | Trench |
|
LPM06P110TN
|
PDFN5*6 | -60 | ±20 | -1.5 | -78 | - | - | 13 | 18.5 | 10.5 | 13.5 | Trench |
|
LPM06P110TD
|
TO252 | -60 | ±20 | -1.5 | -64 | - | - | 13 | 18.5 | 10.5 | 13.9 | Trench |
|
LPM03P080TS
|
SO8 | -30 | ±20 | -1.5 | -12 | - | - | 13.8 | 19 | 10.3 | 13.5 | Trench |
|
LPM03P080TN
|
PDFN5*6 | -30 | ±20 | -1.5 | -60 | - | - | 13.2 | 16 | 9.8 | 13.5 | Trench |
|
LPM03P080TD
|
TO252 | -30 | ±20 | -1.5 | -60 | - | - | 12.5 | 17.5 | 8.8 | 11.5 | Trench |
|
LPM03P048TN
|
PDFN5*6 | -30 | ±20 | -1.5 | -90 | - | - | 7.4 | 9.5 | 5.5 | 7.4 | Trench |
|
LPM03P048TE
|
PDFN3*3 | -30 | ±20 | -1.5 | -50 | - | - | 7.4 | 9.5 | 5.5 | 7.4 | Trench |
|
LPM03P048TD
|
TO252 | -30 | ±20 | -1.5 | -88 | - | - | 6.8 | 8.5 | 5 | 6.5 | Trench |
|
LPM03P080TE
|
PDFN3*3 | -30 | ±20 | -1.5 | -24 | - | - | 12.5 | 17.5 | 8.8 | 11.5 | Trench |
|
LPM4435
|
SOP-8 | -30 | ±20 | -1.2 | -10 | - | - | 24 | 32 | 17 | 21.5 | Trench |
|
LPM4953
|
SOP-8 | -30 | ±12 | -1.7 | 5 | - | - | 65 | 80 | 42 | 50 | Trench |
|
LPM3407A
|
SOT23-3 | -30 | ±20 | -1.6 | 4.1 | - | - | 57 | 73 | 42 | 52 | Trench |
|
LPM3407
|
SOT23 | -30 | ±20 | -1.6 | 2.6 | - | - | 140 | 200 | 100 | 130 | Trench |
|
LPM3401A
|
SOT23 | -30 | ±12 | -0.9 | 4.2 | 85 | 120 | 58 | 68 | 45 | 53 | Trench |
|
LPM9435
|
SOP-8 | -30 | ±12 | -1.7 | 5.8 | - | - | 65 | - | 42 | - | Trench |
|
LPM9017
|
SOT23 | -30 | ±12 | -0.9 | 4 | 85 | 95 | 64 | 68 | 55 | 58 | Trench |
|
LPM9007
|
SOT23 | -30 | ±20 | -1 | 4 | 80 | 120 | 53 | 65 | 42 | 50 | Trench |
|
LPM02P076TE
|
PDFN3*3 | ±12 | -0.5 | -40 | 7.7 | 9.6 | 6.1 | 7.6 | - | - | Trench | |
|
LPM02P060TD
|
TO252 | -20 | ±12 | -0.65 | -76 | 7.6 | 9 | 5.6 | 7 | - | - | Trench |
|
LPM02P060TE
|
PDFN3*3 | -20 | ±12 | -0.65 | -67 | 7.6 | 9 | 5.6 | 7 | - | - | Trench |
|
LPM02P020TN
|
PDFN5*6 | -20 | ±12 | -0.7 | -90 | 3.2 | 4.3 | 2.1 | 2.7 | 1.7 | 2.2 | Trench |
|
LPM9019QVF
|
DFN-6(2*2) | -12 | ±8 | -0.9 | 16 | 23.5 | 30 | 14.3 | 20 | - | - | Trench |
|
LPM9019B3F
|
SOT23 | -12 | ±8 | -0.9 | 6 | 27 | 34 | 17.3 | 22 | - | - | Trench |
|
LPM9015A
|
SOT23 | -15 | ±12 | -0.7 | 5 | 36 | - | 26 | - | - | - | Trench |
|
LPM3413
|
SOT23 | -20 | 12 | -0.55 | 3 | 146 | 190 | 108 | 130 | 81 | 95 | Trench |
|
LPM9015
|
SOT23-3 | 20 | ±8 | 5 | ||||||||
|
LPM2301
|
SOT23 | -20 | ±12 | -0.7 | 2 | 170 | - | 130 | 9 | - | - | Trench |
|
LPM3401
|
SOT23 | -15 | ±12 | -0.9 | 4.2 | 85 | 95 | 64 | 68 | 55 | 58 | Trench |
|
LPM9021A
|
DFN-6(2*2) | -15 | ±12 | -0.7 | 16 | 20 | - | 13 | - | - | - | Trench |
| 产品型号 | 封装 | DS电压最大值(V) | GS电压最大值(V) | VGS（TH） -TYP(V) | 输出电流(A) | RDSON (mΩ) at VGS=2.5V （TYP) | RDSON (mΩ) at VGS=2.5V （MAX) | RDSON (mΩ) at VGS=4.5V （TYP) | RDSON (mΩ) at VGS=4.5V （MAX) | RDSON (mΩ) at VGS=10V （TYP) | RDSON (mΩ) at VGS=10V （MAX) | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LPM9030A
|
SOP8 | 30/-30 | ±20 | 1.7/ -1.7 | 6+5.7 | - | - | - | 40(N-MOS) / 56(P-MOS) | - | 27(N-MOS)/32(P-MOS) | Trench |
|
LPM9030
|
SOP8 | 30/-30 | ±20 | 1.7/-1.7 | 10+7.6 | - | - | - | 28(N-MOS)/55(P-MOS) | - | 18(N-MOS/30(P-MOS) | Trench |
|
LPM9029C
|
SOP8 | 20/-30 | ±10 | 0.65 / -0.65 | 6.5+4.5 | - | 26(N-MOS) /100(P-MOS) | - | 20(N-MOS) /68(P-MOS) | -- | - | Trench |
| 产品型号 | 封装 | DS电压最大值(V) | VGS电压最大值(V) | VGS（TH） -TYP(V) | 输出电流(A) | RDSON (mΩ) at VGS=2.5V （TYP) | RDSON (mΩ) at VGS=2.5V （MAX) | RDSON (mΩ) at VGS=4.5V （TYP) | RDSON (mΩ) at VGS=4.5V （MAX) | RDSON (mΩ) at VGS=10V （TYP) | RDSON (mΩ) at VGS=10V （MAX) | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LPM9050
|
SOT23-6 | 30 | ±20 | 1.8 | 3.6 | - | - | 48 | - | 36 | - | Trench |
|
LPM9042
|
SOP8 | 40 | ±20 | 2.2 | 20 | - | - | 10 | 12.5 | 8.2 | 10 | Trench |
|
LPM9033
|
DFN-8(3*3) | 30 | ±12 | 2.2 | 20 | - | - | 10 | 12.5 | 8.2 | 10 | Trench |
|
LPM9031
|
SOP8 | 30 | ±12 | 1.05 | 5.8 | 24 | 52 | 19 | 33 | 18 | 28 | Trench |
|
LPM9024
|
DFN-6(2*2) | 20 | ±10 | 0.5 | 5 | - | 40 | - | 30 | - | - | Trench |
|
LPM8205
|
SOT23-6/TSSOP8 | 20 | ±12 | 0.75 | 7.6 | 28 | 33 | 20 | 25 | - | - | Trench |
|
LPM9026
|
SOP8 | 20 | 12 | 0.7 | 25 | 11 | 18 | 9 | 12 | - | - | Trench |
|
LPM9022
|
DFN-8(2*3) | 20 | 12 | 0.5 | 6 | - | 26 | - | 20 | - | - | Trench |
