The LP6482 contains an independent 340KHz constant frequency, current mode, PWM step-down converters. The converter integrates a main switch and synchronous rectifier for high efficiency without an external schottky diode. The converter can supply 2A of load current. The LP6482 can also run at 98% duty cycle for low dropout applications. It provides fast transient response and cycle-by-cycle limit with current mode control. The LP6482 is available in a SOP8package and is rated over the -40°C to 85°C temperature range.
应用
◆ Portable Media Players ◆ Cellular and Smart mobile phone ◆ PDA/DSC ◆ GPS Applications
数据参数
数据参数
输入电压(V)
4.5~36
输出电压(V)
0.6~12
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
340K
最大输出电流(A)
2
输出通道数量
1
工作模式
Syn.
EN控制
Y
轻负载模式
FCCM
产品特征/功能
Internal Soft Start,OCP,SCP,OTP
封装
SOP8
特征
特征
◆ Input Voltage Range: 4.5V to 30V ◆ Output Voltage Range: 0.6V to 12V ◆ 2A Load Current ◆ Up to 95% Efficiency ◆ 340KHz Switching Frequency ◆ Short Circuit Protection ◆ Thermal Fault Protection ◆ SOP8 Package ◆ RoHS Compliant and 100% Lead (Pb)-Free
