The LP6492 is a synchronous, rectified, step-down,switch-mode converter with built-in power MOSFET.The LP6492 offers a very compact solution that achieves a maximum of 2.4A of continuous output current. The LP6492 has synchronous mode operation for high efficiency over the output current load range. Current-mode operation provides fast transient response and eases loop stabilization.The LP6492 requires a minimum number of readily available standard external components. Other features include cable compensation, programmable current limit and thermal shutdown
应用
◆ Car Charger ◆ Pre-Regulator for Linear Regulators ◆ Distributed Power Systems ◆ USB Dedicated Charging Ports (DCP)
数据参数
数据参数
输入电压(V)
8.0~36
输出电压(V)
0.6~30
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
180K
最大输出电流(A)
2.4
输出通道数量
1
工作模式
Syn.
EN控制
N
轻负载模式
FCCM
产品特征/功能
Adjustable output current limit,Line compensation
封装
SOP8
特征
特征
◆ Wide 8V to 30V Continuous Operating Input Range ◆ 78mΩ/65mΩ Low RDS(ON) Internal Power MOSFET ◆ Up to 93% Efficiency ◆ Default 160kHz Switching Frequency ◆ Internal Soft Start ◆ Output Line Drop Compensation ◆ Over-Current Protection (OCP) programmable with External Resistor ◆ No Loop Compensation Required ◆ Thermal Shutdown ◆ Available in SOP-8 Package
