概述
LP1140 is a highly integrated full bridge power IC optimized for wireless power transmitter solutions. The device integrates all critical functions such as high-efficiency power FETs, low EMI FET driver,
bootstrap circuit, 3.3V and 5V LDO and lossless current measurement.LP1140 also includes protection functions such as input under-voltage lockout, short-circuit protection, and thermal shutdown. These provisions further enhance the reliability of the total system solution.The LP1140 are available in the industry standard QFN-20 packages.
应用
◆ Wireless Power Transmitter
◆ Motor Drivers
数据参数
数据参数
输入电压(V)
4.3~13.2
静态电流(uA)
900
输出电流 (A)
5*2
特点
全桥
封装
TQFN-20(4*4)
特征
特征
◆ Up to 24V DC VIN voltage
◆ 4.2V to 15V supply voltage(PVINX)
◆ Output Power: 15W
◆ Integrated High Efficiency Full Bridge FETs
◆ Integrated FET Driver Optimized for Low EMI
◆ Integrated 3.3V/5V LDO to Bias External Circuit
◆ Input Under-Voltage Lockout
◆ Short-Circuit Protection
◆ Thermal Shutdown
◆ Available in 4mm × 4mm QFN-20 Package
